參數|數據|型號 |
YGL-180M
|
YGL-300M
|
YL(G)L-350M |
YL(G)L-460M
|
YL(G)L-700M
|
YL(G)L-1000M
|
YL(G)L-1200M
|
YL(G)L-1400M
|
YL(G)L-1900M
|
||
|
額定功率KW |
180
|
300
|
350
|
460
|
700
|
1000
|
1200
|
1400
|
1900
|
||
|
供熱量×104kcal/h |
15
|
25
|
30
|
40
|
60
|
80
|
100
|
120
|
160
|
||
|
熱效率% |
71
|
71
|
71(66)
|
71(66)
|
71(66)
|
76(74)
|
76(74)
|
76(74)
|
76(74)
|
||
|
設計壓力MPa |
0.7
|
0.7
|
0.7
|
0.7
|
0.7
|
1.1
|
1.1
|
1.1
|
1.1
|
||
|
工作溫度℃ |
320
|
320
|
320
|
320
|
320
|
320
|
320
|
320
|
320
|
||
|
介質循環量m3/h |
12.5
|
40
|
40
|
60
|
80
|
100
|
100
|
100
|
100
|
||
|
爐內介質容量m3 |
0.15
|
0.3
|
0.4
|
0.5
|
0.7
|
1
|
1.1
|
1.2
|
1.6
|
||
|
主管口徑DN |
40
|
80
|
80
|
100
|
100
|
125
|
125
|
125
|
150
|
||
|
裝機容量KW |
8.5
|
15
|
18(15)
|
24(20)
|
28(25)
|
45(40)
|
53(48)
|
60(55)
|
80(73)
|
||
|
適用煤種 |
煙煤、無煙煤 |
||||||||||
|
煤耗量Kg/h |
48 |
75 |
85(91) |
110(118) |
170(183) |
225(263) |
280(300) |
340(365) |
455(490) |
||
|
鼓風機 |
型號 |
-
|
T4-72 3A
|
T4-72 3A
|
T4-72 3A
|
TA-72 3A
|
T4-72 3.5A
|
T4-72 3.5A
|
T4-72 3.5A
|
TA-72 4A
|
|
|
流量m3/h |
-
|
1588-3049
|
1588-3049
|
1588-3049
|
1588-3049
|
2522-4841
|
2522-4841
|
2522-4841
|
3764-7226
|
||
|
風壓Pa |
-
|
1142-716
|
1142-716
|
1142-716
|
1142-716
|
1556-976
|
1556-976
|
1556-976
|
1275-2036
|
||
|
功率KW |
-
|
1.5
|
1.5
|
1.5
|
1.5
|
3
|
3
|
3
|
5.5
|
||
|
引風機 |
型號 |
YX5-47 4C
|
YX5-7 4C
|
YX5-47 4C
|
YX5-47 5C
|
YX5-47 5C
|
YX9-35 6.3C
|
YX9-35 6.3C
|
YX9-35 6.3C
|
YX9-35 8C
|
|
|
流量m3/h |
2750-5060
|
3130-5750
|
3130-5750
|
4840-8900
|
4840-8900
|
9474-10626
|
9474-10626
|
9474-10626
|
15627-17528
|
||
|
風壓Pa |
1451-990
|
1873-1284
|
1873-1284
|
1843-1265
|
1843-1265
|
2452-2393
|
2452-2393
|
2452-2393
|
2383-2334
|
||
|
功率KW |
3
|
4
|
4
|
5.5
|
5.5
|
11
|
11
|
11
|
18.5
|
||
|
循環泵 |
型號 |
50-50-170
|
80-50-180
|
80-50-180
|
100-65-190
|
100-65-200
|
100-65-230
|
100-65-240
|
100-65-257
|
125-80-250
|
|
|
流量m3/h |
12.5
|
40
|
40
|
60
|
60
|
100
|
100
|
100
|
160
|
||
|
揚程m |
32
|
40
|
40
|
38
|
38
|
55
|
70
|
80
|
60
|
||
|
功率KW |
4
|
7.5
|
7.5
|
11
|
11
|
22
|
30
|
37
|
45
|
||
